Specialized Grand Piano Action with Ivorite Keytops
Non-contact optical sensor system
Key Sensor type: Continuous grayscale
Hammer Sensor type: Shutter type
4-point Spatial Acoustic Sampling Technology
4ch Spatial Acoustic Speaker System
Tactile Response System
5 playable voices
Recording formats: Standard MIDI
Supported file formats: Standard MIDI
Compatible storage media: USB Flash Memory (up to 8GB)
MIDI connectivity: 5-pin MIDI IN/OUT
Audio connectivity: analog audio IN x2 (TS), analog audio OUT x 2 (TS)
Headphone connectivity: 1/4” stereo x 2
Data connectivity: USB TO DEVICE x 1
Speaker output: 2watts x 10, 80watts x2
- HPH-100 Closed-Back Headphones
- HPH-150 Open-Air Headphones
- Free APP – Smart Pianist
- Owner’s Manual
- Power Cord
- Matching Bench
The nuanced touch and response of the grand piano are an essential standard yardstick for piano quality. It offers the player a specially-developed grand piano action that features the same configuration as the action of a real grand. The hammers strike the “strings” from underneath, allowing minute adjustments to the weight distribution of the hammers, and to the movement of the hammers themselves, for a smoother feel when playing. In addition to a hammer sensor, this instrument employs a non-contact key sensor that has no effect on the movement of the keys, affording excellent recognition of the player’s pressure on the keyboard, timing, and the other delicate nuances that affect musical expression. This combination provides an impressive sensitivity for the entire range from pianissimo through to fortissimo, and the ability to translate even the swiftest trills of the pianist with transparency. The wood construction of the keyboard mirrors that of the grand piano, and features New Ivory II on the white keys. This is a unique new material developed by Yamaha, with a texture superbly close to that of natural ivory, allowing you to play swift passages with ease while also offering a sure response for slower pieces.
Together with a variety of piano sounds, this instrument features samples of the actual vibrations from within the soundboard of the instrument. To permit the sound to travel well to the player’s position, as it does with a grand piano, we sampled the sound from four locations in the left, right, center, and rear of a grand piano. Sampling from deeper inside the instrument, we were able reproduce the attraction of the original sound almost perfectly. It was the experience of our engineers, and a reiterative cycle of trial and error conducted with piano tuners that made this success possible. And of course, the samples in this instrument are all taken from a specially-selected example of Yamaha’s CFIIIS full concert grand piano.
This instrument utilizes a four-channel multi-speaker system, designed in a three-way configuration with woofer, squawker and tweeter, to allow more natural reverberation in the soundboard. Each of the speakers in this layout is equipped with its own dedicated amplifier, a luxury that reduces the interference in each pitch range and offers more natural expression to the delicate nuances in each sound. Moreover, by using speaker positioning that mimics the positions in the grand piano from which the original samples were taken, it offers a more natural sound to the pianist.
The sound of an acoustic piano resonates throughout its entire body. The bass range in particular is an essential part of the reverberation that is continually transmitted to a player’s body. This is replicated by our newly-developed Tactile Response System (TRS) that focuses on reproducing reverberation. This system features two transducers in the soundboard, the area underneath the keyboard, resonating natural reverberation throughout the entire instrument. The player’s hands on the keyboard transmit the natural sound felt from the feet as they depress the pedals; the epitome of real piano playing. This system can be turned on and off, and the vibration set to one of three levels.
